Universal
Fits every sectional door up to 334 kg without structural changes, from residential 3.5 × 3.5 m to industrial 6 × 5 m.
Spring-free sectional door automation
One patented kit automates industrial and residential sectional doors. No structural changes.
- no balancing springs or lifting cables
- 0 springs
- maximum door weight, doors up to 6 × 5 m
- 334 kg
- side room, guides included
- 150 mm
- cycles tested to EN 13241, 12604 and 12453
- 100,000
The product
Pre-engineered overhead drive, with no springs to tension
Motor, lifting belts and safety brake sit inside a unified lintel shaft assembly, for rapid installation and low-maintenance operation.
-
Direct drive, no counterbalance
A brushless tubular motor with a built-in inverter turns the shaft directly. There are no springs to size, tension or replace.
-
Adjusts to the opening on site
A centre bearing and a rigid coupling join the two shaft sections, so one kit adapts by up to 50 cm in width with no special calculations.
-
Fall protection built in
A safety brake on its own shaft holds the door if the drive ever fails, with up to 1,444 Nm of anti-fall torque.
Key strengths
Fewer parts, faster installation
Modular
Six kits, 100 to 200 Nm, width-adjustable by up to 50 cm. Configure on site without re-engineering.
Strong
Tested for 100,000 cycles. Safety brake with up to 1,444 Nm anti-fall torque. Rated −10 °C to +40 °C.
Patents and recognition
Patented, and an R+T Innovation Award 2027 finalist
The spring-free drive is our own design, protected by 2 worldwide patents. The UniLift System is a finalist for the R+T Innovation Award 2027, presented at R+T in Stuttgart, the world’s leading trade fair for roller shutters, doors and sun protection.
Every kit is built to CPR 305/2011, the Machinery Directive 2006/42/EC and EN 13241, EN 12604 and EN 12453.
- Finalist, R+T Innovation Award 2027
- 2 worldwide patents
- CE-certified components
- Designed and assembled in Italy
R+T Innovation Award 2027UniLift System · Finalist
Advantages
Built for installers, resellers and maintenance teams
Operations
- Plug-and-play installation
Guides included, only 150 mm of side room. Assembly is quick and no springs are needed.
- Pre-wired
Control unit and motor arrive pre-wired, so you can commission straight away.
- Less maintenance
No springs or lifting cables to service or replace. The emergency chain still works in a power cut.
Logistics
- Fewer kits
Two or three kits cover your whole door range.
- Standard parts
One universal support fits every configuration.
- Export-friendly
Parts ship in lengths up to 3 m.
Technology & circular design
- One universal shaft
Sized by door weight and adjustable by up to 50 cm, with no special calculations.
- Ready for accessories
A shaft profile that takes accessories directly, with no machining.
- Eco-friendly design
Built to current environmental best practice and ESG rules.
Delivery
Minimal shipping footprint
A complete drive travels in three compact cartons, none heavier than 19 kg: lower freight costs, less shelf space and boxes one person can carry. Aluminium shafts are ordered by length, in 2, 3 or 7 m; with MTB‑EXP the longest piece is 1 m.
- Motor box: up to 698 × 200 × 190 mm, 14 kg
- Control unit box: 370 × 270 × 150 mm, 3 kg
- Accessories box: up to 510 × 250 × 196 mm, 19 kg
Technical documentation
Access the catalogue and manuals in the Customer Area
Every installation step, wiring diagram, setting and maintenance task, for installers and partners with a free business account.
No account yet? Create one
Customer Area
- Installation, wiring, settings, maintenance
- Brushless motor manual
- English, Italian, French, Spanish and Hungarian, online and as PDF
- Readable on a phone on site
Tell us about your doors
Send us the door sizes and we reply with a quote within one working day.
